Product Portfolio of 1ST-embedded GmbH

To make it easier for you to use our products, we enable the selection and ordering of sample quantities and small quantities of our products in our B2B shop with a variant selection that we have predetermined. For other configurations as well as for serial quantities and framework contracts, please contact us or ask us for a separate offer. To get the access data to our shop please contact us.

Of course, regardless of the number of pieces you can always contact us with your questions. We try to give you the best support for your project and we look forward to hearing from you by phone, email or via our contact form.

Our offer is aimed exclusively at companies, traders and public institutions. The prices listed here are net plus statutory VAT and shipping costs from Hamburg.

Sale
Mini ITX Embedded Motherboard 1ST-MITX-TL10
Industrial Mini-ITX-motherboard with 11th Generation Intel® Core™ i3/ i5/ i7 processor (Tiger Lake) or Celeron™ processor 6305 with 4x HDMI 2.0.
This Embedded Motherboard has 2x DDR4-SO-DIMM-slots for up to 64 GB RAM, 2x GbE LAN ports, 2x USB 3.0 and 4x USB 2.0, 1x SATA, 3x M.2 for NVMe SSD, WiFi and 4G/5G Modem and one PCIe x2 expansion slot.
Sale
Industrial Mini ITX-Motherboard 1ST-MITX-FP-10
AMD Ryzen™ Embedded V1000-based mini-ITX board with 4x DisplayPort 1.2, 2x GbE LAN, 2x SO-DIMM DDR4 Sockets for up to 32 GB RAM, 2x USB3, 2x USB2, Realtek HD ALC662 Audio (Line-out, Mic-in), 1x SATA, 1x M.2 for WiFi, 1x M.2 for 4G/2280 SSD, 1x PCIe x1, 1x PCIe x4, internal 6x USB2 header, 6x COM header, 8x GPIO, 1x LVDS/eDP header, 1x JLPT, 1x PS2_H, TPM2.0 optional
Sale
Thin Mini-ITX Embedded Motherboard 1ST-MITX-WL10
Industrial Mini ITX Motherboard
with 8th Gen Intel® Core™ i3/ i5/ i7 processor or Celeron™ processor 4205U. This embedded Board features multiple display via DP1.2, HDMI 1.4 and eDP or LVDS.
This Embedded Motherboard has 2x LANs and supports 4G network.
It carries 1x DDR4 SO-DIMM 2400MHz slot up to 16GB to add higher bandwidth and lower latencies for processes.
Sale
i.MX6 embedded board EMB-3501
i.MX6 -S/DL/Q based embedded board with 1GB RAM and 8GB Flash onboard, VGA, HDMI, LVDS multi Display interface, 5xCOM, 2xSATAII, 1xMicro SD slot, 5xUSB2.0, 1xUSB OTG, 1xLAN,
Line out + Line in+ MIC in, power amplifier, 2x5 W 2Ω audio, 1x Mini PCIe for 3G-Module,1xSIM socket, 18-bit GPIO, Operating Temperature: -20 ...+60°C, Dimensions: 146mmx102mm
Sale
Industrial nano-ITX Board EMB-3500Q04
Embedded nano-ITX Board with Arm® Cortex® A9 i.MX6 quad-core CPU, 4x COM, 1GB DDR3 Memory, 2x 10/100/1000 Mbps LAN, 1x SATA2, 1x Micro SD, 1x MiniPCIe, 1x HDMI, 1x VGA, 2x 24bit Dual Channel LVDS, 5x USB2.0, 1x USB (OTG), 40 bit GPIO, Audio Line-In, Line-out, Mic. pin, Watchdog Timer, -20°C to +60°C Operating Temperature Range, -40°C to +80°C Storage Temperature, 5% to 95% Relative Humidity, Non-Condensing, +12V DC Power Input, Dimensions: 120 mm x 120 mm
Sale
Thin Mini-ITX Embedded Motherboard 1ST-MITX-KL10
Industrial Thin Mini-ITX Motherboard
with 7th Gen Intel® Core™ or Celeron® Processor (Kaby Lake), 3x M.2, 2x LAN
